When students first encounter Simple Harmonic Motion (SHM) and Waves in A-Level Physics, the concepts can feel abstract and mathematical. But with the right breakdown, these topics become logical and even intuitive. Here’s a clear definition of the key ideas and the knowledge you’ll need to master.
At PivotPhysics, we guide students through these concepts step-by-step, ensuring not just memorisation, but deep understanding and confident application in exam settings.
What is Simple Harmonic Motion (SHM)?
Simple Harmonic Motion
SHM describes the motion of an object where the restoring force is directly proportional to its displacement and acts in the opposite direction.
Examples include:
- A mass on a spring oscillating back and forth
- A simple pendulum swinging with small amplitude
- A vibrating tuning fork producing sound waves
In A-Level Physics,
Definition: SHM is a type of oscillatory motion where the acceleration of a particle is always directed towards a fixed equilibrium point and is proportional to its displacement from it.
Simplified explanation: SHM is a back-and-forth movement where an object always tries to return to a central resting point (equilibrium). The farther it is from this point, the stronger the “pull” back—like a spring or a swinging pendulum (pictured above).
Key formula to know:
Acceleration in SHM:
a = -ω²x
Displacement as a function of time:
x(t) = A sin(ωt + φ) or x(t) = A cos(ωt + φ)
Velocity in SHM:
v(t) = ±ω√(A² – x²)
Period and Angular Frequency:
T = 2π / ω
ω = 2πf
Examples of Period Calculation:
- Mass-spring system: T = 2π√(m / k)
- Simple pendulum: T = 2π√(l / g)
Waves – A Quick Recap
Waves
Waves are taught in the O Level syllabus but are further elaborated in the A Level syllabus. In essence waves transfer energy without the transfer of matter.
Students study two main types:
- Mechanical waves – require a medium (sound waves, water waves)
- Electromagnetic waves – do not require a medium (light, radio waves)
In the A Level syllabus 9748 (2026), emphasis is placed on 3 main content strands.
-
Wave Properties
-
Energy Transfer by Progressive Waves
-
Polarisation
Core knowledge needed:
- Wave properties: wavelength (λ), frequency (f), amplitude, and wave speed (v=fλ).
- Transverse vs longitudinal waves.
- Superposition principle and interference.
- Standing waves: nodes, antinodes, and resonance conditions.
Applications: musical instruments, diffraction patterns, signal transmission.
.
Why SHM and Waves are Challenging
Many students struggle because:
- The concepts are abstract and require visualising motion and energy changes over time
- Equations link multiple variables, requiring algebraic manipulation and trigonometric understanding
- Exam questions often test multi-step problem solving, combining graphical interpretation, formula application, and logical reasoning
Why This Matters in A-Level Physics Tuition
Tuition helps students by breaking these abstract ideas into visual and practical lessons—using pendulum experiments to show SHM, or ripple tanks and simulations to demonstrate wave interference. By mastering SHM and Waves, students not only strengthen their exam preparation but also build intuition for later topics such as quantum physics and oscillations in electrical systems.
